100w ETFE sunpower solar panel kit portable solar panel blanket small light quick connect goal zero portable solar generator
emobi F5*20w,sp
EXW,CIF,FOB
10 pieces
2000pieces / Month
SHENZHEN
12-30Day
Quantity
Our folding solar panel 100 watt is a perfect portable solution for powering up your devices on the go. With a foldable and lightweight design, this solar panel can easily be transported and ideal for camping, hiking, or travel.
- Place of Origin:China
- Brand Name:OEM /AHONY
- Model Number:emobi F5*20w,sp
- Type:IBC, 100w sunpower folding solar kit
- Panel Dimensions:420*290*40MM
- Panel Efficiency:22.6%
- Certificate:CE ROHS ISO
- Warranty:1 year
- Solar cell:SunPower Maxeon Gen III Back Contact Cell
Product Description
| Model No. | eMobi F5x20w |
| Product Name | 12V folding solar kits |
| Maximum Power[Wp] | 100 |
| Solar Cell | SunPower Maxeon Gen III Back Contact Cell |
| Cell Efficiency | 22.60% |
| Folded Size[mm] | 420*290*40 |
| Open Size[mm] | 1715*420*4 |
| Max Power Voltage Vmp[V] | 18.60 |
| Max Power Current Imp[A] | 5.38 |
| Open Circuit Voltage Voc[V] | 21.95 |
| Short Circuit Current Isc[A] | 5.81 |
| Net.Weight[kg] | 3.4 |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/℃] | -0.4 |
| Temperature Coefficient Voc[[mV/℃] | -2mV |
| Temperature Coefficient Isc[mA/℃] | 0.037 |
| Maximum System Voltage[V] | 100 V |
| Certification | CE ROHS |
| Suface/backsheet | PET+ETFE |
| Charge controller | PWM 10A 12/24V,2 USB,LCD display |
| Cables | 1m 14AWG cable |
| Connector | MC4 |
| Supporting Leg | Yes |
| Eyelets | No |
| Standard Test Conditions | STC: 1000W/m², AM 1.5 and cell temp 25°C |
| Package | 1pcs/bubble plastic bag,then in 1 carton box |
Packaging & Shipping
