100w 120w 135w 150w 200w 220w flexible solar panel for boat yacht marine RV outdoor camping application Flexible light weight solar panel 135W SunPower boat yacht marine solar panel flexible solar panel 135W SunPower solar panel flexible solar panel fo
Factory Wholesale 60W to 400W PV Module PERC Mono ETFE Flexible Solar Panel High-Efficiency Solar Panels
price

$0.82 - $0.95 / piece

eGO S135W
1 piece
Quantity
  • Brand Name:Ahony Power
  • Model Number:eGO S135W
  • Place of Origin:Guangdong, China
  • Cell size:125mmx125mm
  • Type:PERC
  • Panel Dimensions:540x1330x3mm`
  • Panel Efficiency:22.6%
  • Brand:Ahony Power
  • Product name:eGO S135W
  • Product Keywords:Solar Panel
  • Junction Box:PV-XC505
  • Warranty:1 Year
  • Certificate:CE RoHS
  • Cell:SunPower
  • Number of Cells:4*10

Product Description

 eGo S mono solar panel flexible 120W 18V 12V Solar Panel Monocrystalline Cell Flexible Bendable Lightweight Waterproof Off grid uses high efficiency solar cell,USA back contact SunPower cell,cell efficiency is from 22.4% to 23.7%.ETFE surface from Japan,it can resist high temperature at 242℃,material transmittance is over 95%.More over,it has excellent tensile strength,low water absorption,makes the flexible panel higher waterproof.



eGo S is more flexible than conventional cell flexible like eGo P,it can bend 30° arc at maximum,It’s aerodynamic design that can reduce wind resistance when install on rooftop of RV or yacht.

eGo S is perfect for all mobile use like caravan,boat,marine,motor etc.There are different power and size from 7w to 150w.Also two colours white and black can be used for any panel.Currently flexible solar panel is widely used for mobile,marine,camping industry,Now more and more people concern about eGo S flexible.




















































































































Model No.eGo S135w
 Features mono solar panel flexible 1354W 18V 12V Solar Panel Monocrystalline Cell Flexible Bendable Lightweight Waterproof Off grid
Product NameSemi-Flexible Solar Panel
Maximum Power[Wp]135
Solar CellBack Contact Cell
Cell Array[Pcs]4*10
Cell Efficiency24.40%
Size[mm]550x1220x5
Max Power Voltage Vmp[V]22.6
Max Power Current Imp[A]5.98
Open Circuit Voltage Voc[V]26.00
Short Circuit Current Isc[A]6.34
Net.Weight[kg]5.2
Power tolerance[%]±5%
NOCT[℃]45±2
Operating Temperature[℃]-40/+85
Temperature Coefficient Pmax[%/K]-0.3
Temperature Coefficient Voc[[%/K]-1.74mV
Temperature Coefficient Isc[[%/K]0.05
Maximum System Voltage[V]200 V
Maximum Reverse Current[V]0A
CertificationCE ROHS
Surface/BacksheetJapan ETFE/white plastic
Maximum bend radius(θ)30°
Cables and ConnectorsPV-XC502 Jbox IP65,0.9m cable and 1 pair of MC10 connector
Standard Test ConditionsSTC: 1000W/m², AM 1.5 and cell temp 25°C
Other notesround corner R10,with eyelets
Package1pcs/Polyethylene foam(EPE Foam),then in 1 carton box








Packaging & Shipping


This is mono flexible solar panel 120W with fast delivery,there are a lot of delivery option you can choose.








Our Services


 AHONY offer a series of mono flexible solar panel 120W with fast delivery after sale service:
Install and debug products for customers;
According to the requirements of consumers, carry out technical guidance on the use and other aspects;
Process:
1.Report problem of exact mono solar panel bendable type to the salesman you contact or sales manager.
2.After-service Respond, We will check order information (sequence number, model),
record problem, instruct client to inspect the problem by video. Confirm the necessary info if repairing or replacing is needed.
3.Follow up, We will follow up clients whether the problem is solved or whether any further service need.
4.Our sales person,engineer will follow up with customers need,regular feedback on products,to make sure customers are always satisfy with
products and service.
