200 watt folding solar panel Portable solar kit solar blanket to charge portable generator for camper trailer rv motorhome
eMobi F10*20w,200w
EXW,CIF,FOB
10 pieces
2000pieces / Month
SHENZHEN
12-30Day
Quantity
The 200 watt Folding solar panel is a powerful and portable solution for charging your batteries while on the go. With its efficient solar cells and folding design, it can generate enough power to charge your batteries and run your devices, making it perfect for off-grid camping trips.
- Warranty:1 year, 1 Year
- Free installation service:NO
- Place of Origin:Guangdong, China
- Brand Name:OEM or AHONY
- Model Number:eMobi F10*20w,200w
- Application:Home
- Solar Panel Type:Monocrystalline Silicon
- Controller Type:PWM
- Mounting Type:Ground Mounting
- Load Power (W):400-1200wh, 200w
- Output Voltage (V):20v
- Output Frequency:50Hz
- Work Time (h):5
- Certificate:CE RoHS ISO9001
- Pre-sales project design:Y
- Battery Type:Lithium
- Solar panel:Monocrystalline PET solar panel blanket
- Product name:Portable solar kit solar blanket 200w
- Material:textile foldable solar kit and ETFE flexible solar panel
- application:solar for camper trailer rv motorhome military remote medical care
- Mounting brackets:with supporting leg no need mounting brackets
Product Description
AHONY eMobi F10x20w portable solar kit has the best size that is suitable for RV,the voltage is 18V which is better for 12v battery.
Back contact solar cells,efficienty is over 21.4%;
All parts cables,connectors,charge controller in 1 suitcase,portable and light weight
PET surface,more weather resistance;
Waterproof Jbox that is full of silicon gel;
Customize is acceptable.
High quality Portable solar kits solar blanket to charge portable generator can use everywhere
Now foldable solar blanket is more and more popular in camping solar,marine solar,disaster recovery,remote medical care,portable solar generator,millitary portable solar charger,hiking,motorhome,travel etc.
| Model No. | eMobi F10x20w |
| Product Name | 200w Portable solar kit solar blanket to charge portable generator for camper trailer rv motorhome military remote medical care |
| Maximum Power[Wp] | 200 |
| Solar Cell | Mono PERC A Grade Solar Cell |
| Cell Efficiency | 21.40% |
| Folded Size[mm] | 400*360*80 |
| Open Size[mm] | 1715*780*4 |
| Max Power Voltage Vmp[V] | 20.16 |
| Max Power Current Imp[A] | 9.92 |
| Open Circuit Voltage Voc[V] | 23.79 |
| Short Circuit Current Isc[A] | 10.71 |
| Net.Weight[kg] | 7/8.15 |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/℃] | -0.4 |
| Temperature Coefficient Voc[[mV/℃] | -2mV |
| Temperature Coefficient Isc[mA/℃] | 0.037 |
| Maximum System Voltage[V] | 100 V |
| Certification | CE ROHS |
| Suface/backsheet | PET+FR4 fibreglass |
| Charge controller | PWM 10A 12/24V,2 USB,LCD display |
| Cables | 5m 14AWG cable |
| Connector | MC4+battery clips |
| Supporting Leg | No |
| Eyelets | Yes |
application
