The 90 watt solar panel is a compact and efficient source of solar power. With a durable design and high-energy output, it's ideal for charging small devices and powering off-grid applications. Get the most out of solar energy with a 90 watt solar panel.
ETFE surface sunpower semi flexible 90 watt solar panel for electric boat camping RV motorhome boat
eGo-S90w
EXW,FOB,CIF
10 pieces
2000pieces / Month
SHENZHEN
12-30Day
Quantity

The 90 watt solar panel is a compact and efficient source of solar power. With a durable design and high-energy output, it's ideal for charging small devices and powering off-grid applications. Get the most out of solar energy with a 90 watt solar panel.

  • Place of Origin:Guangdong, China
  • Brand Name:Ahonypower
  • Model Number:eGo-S90w
  • Type:IBC, Customized Solar Panel
  • Panel Dimensions:540x940x3mm
  • Panel Efficiency:22.6%
  • Certificate:CE ROHS ISO9001
  • Warranty:1 year, 1 Year
  • Product name:90w solar panel flexible solar panel
  • Application:Boat,RV,Marine,Yacht,van etc.
Product Description
Model No.eGo S90w
Product NameSemi-Flexible Solar Panel
Maximum Power[Wp]90
Solar CellSunPower Maxeon Gen III Back Contact Cell
Cell Array[Pcs]4*7
Cell Efficiency22.70%
Size[mm]540*940*3
Max Power Voltage Vmp[V]18.56
Max Power Current Imp[A]5.12
Open Circuit Voltage Voc[V]21.90
Short Circuit Current Isc[A]5.53
Net.Weight[kg]1.1
Power tolerance[%]±5%
NOCT[℃]45±2
Operating Temperature[℃]-40/+85
Temperature Coefficient Pmax[%/K]-0.3
Temperature Coefficient Voc[[%/K]-1.74mV
Temperature Coefficient Isc[[%/K]0.05
Maximum System Voltage[V]100 V
Maximum Reverse Current[V]10A
CertificationCE ROHS
Surface/BacksheetJapan ETFE/white plastic
Maximum bend radius(θ)30°
Cables and ConnectorsPV-XC502 Jbox IP65,0.9m cable and 1 pair of MC4 connector
Standard Test ConditionsSTC: 1000W/m², AM 1.5 and cell temp 25°C
Other notesround corner R10,with eyelets
Package1pcs/Polyethylene foam(EPE Foam),then in 1 carton box
Lead timewithin 12-15working days after payment confirmed.
Payment terms30% in advance as deposit balance before shipment.
Price TermsFOB Shenzhen,China.
Warranty

Power output will be at least 95% after 5 years and more than 85% after 10 years,2 years repair/replacement.
