Flexible ultralight solar panel 100W for rv marine boat yacht ocean use
eGo-LS100w
EXW,CIF,FOB
10 pieces
2000pieces / Month
SHENZHEN
12-30Day
Quantity
Our flexible ultralight solar panel offers a lightweight and durable energy solution for your off-grid needs. With a bendable and resilient design, it's perfect for backpacking, hiking, and other outdoor activities. Upgrade to our ultralight flexible solar panel for convenient and eco-friendly energy on the go!
- Brand Name:Ahony
- Model Number:eGo S100w
- Place of Origin:Guangdong, China
- Type:PERC, Customized Solar Panel
- Panel Dimensions:10*1220*4.5
- Panel Efficiency:22.6%
- Certificate:CE ROHS
- Warranty:1 year
- Product name:Light weight solar panel
- Solar cell:Mono 156*156 Cell
Product Description
| Product Name | eGo L100M-18v |
| Maximum Power[Wp] | 100 |
| Solar Cell | Monocrystalline solar cell |
| Cell size[mm] | 156*97.4 |
| Cell Array[Pcs] | 3*12 |
| Cell Efficiency | 21.00% |
| Size[mm] | 510*1220*4.5 |
| Max Power Voltage Vmp[V] | 19.80 |
| Max Power Current Imp[A] | 5.05 |
| Open Circuit Voltage Voc[V] | 23.36 |
| Short Circuit Current Isc[A] | 5.45 |
| Net.Weight[kg] | 3.8 |
| Power tolerance[%] | ±5% |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/℃] | -0.43 |
| Temperature Coefficient Voc[[%/℃] | -0.34 |
| Temperature Coefficient Isc[[%/℃] | 0.05 |
| Maximum System Voltage[V] | 200 V |
| Maximum Reverse Current[V] | 10A |
| Certification | CE ROHS |
| Surface/Backsheet | ETFE/white plastic |
| Maximum bend radius(θ) | 10°-20° |
| Cables and Connectors | PV-XC502 Jbox IP65,0.9m cable and 1 pair of MC4 connector |
| Standard Test Conditions | STC: 1000W/m², AM 1.5 and cell temp 25°C |
| Other notes | round corner R10,with eyelets |
| Package | 1pcs/Polyethylene foam(EPE Foam),then in 1 carton box |
| Lead time | within 12-15working days after payment confirmed. |
| Payment terms | 30% in advance as deposit balance before shipment. |
| Price Terms | FOB Shenzhen,China. |
| Warranty | Power output will be at least 95% after 5 years and more than 85% |
Packaging & Shipping
