OEM customize 1.2A backpack solar panel 7w 6v
eMobi F7w
EXW,CIF,FOB
10 pieces
2000pieces / Month
SHENZHEN
12-30Day
Quantity
Charge your devices on-the-go with our Small Backpack Solar Panel. Our lightweight and compact panels are perfect for hikers, campers, and outdoor enthusiasts who need a sustainable power source for their devices. Easy to use and durable, our small backpack solar panels are the ultimate solution for staying connected on your outdoor adventures.
- Warranty:3months-1year
- Place of Origin:Guangdong, China
- Brand Name:AHONY or OEM
- Model Number:eMobi F7w
- Battery:no
- Folding Size:185*250*5mm
- Socket Type:USB
- USB Port:1 pcs 5v
- Certificate:CE ROHS
- style:backpack solar bag
- Application:camp hike climb
- Feature:plug to bag directly solar panel
7w solar bag backpack use solar panel,plug to bag directly.
| Model No. | eMobi F7w |
| Product Name | Solar panel for backpack |
| Maximum Power[Wp] | 7 |
| Solar Cell | A grade mono perc cell |
| Cell Array[Pcs] | 1*12 |
| Cell Efficiency | 23.00% |
| Size[mm] | 185*250*5 |
| Max Power Voltage Vmp[V] | 6.96 |
| Max Power Current Imp[A] | 1.01 |
| Open Circuit Voltage Voc[V] | 8.21 |
| Short Circuit Current Isc[A] | 1.09 |
| Net.Weight[kg] | 0.5 |
| Power tolerance[%] | ±5% |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/K] | -0.4 |
| Temperature Coefficient Voc[[%/K] | -2mV |
| Temperature Coefficient Isc[[%/K] | 0.037 |
| Maximum System Voltage[V] | 100 V |
| Maximum Reverse Current[V] | 10A |
| Certification | CE ROHS |
| Surface/Backsheet | PET/black backsheet,cover copper ribbon |
| Maximum bend radius(θ) | 10° |
| Cables and Connectors | USB male+0.3m cable+USB female |
| USB | 1pcs,panel max output current 5V 1.4A(USB can load 5v 2.4A),automatically restart |
| Cable pocket | yes |
| Sew buckles | Yes,sew 4pcs buckles |
| Standard Test Conditions | STC: 1000W/m², AM 1.5 and cell temp 25°C |
