The Photovoltaic glass caravan solar kit is a reliable and cost-effective solution for off-grid power. With advanced glass solar panels and a durable mounting system, it delivers high-efficiency energy for your mobile home.
1.high efficiency
The efficiency of back conact cell efficiency 80w solar panel is up to 22%
2.Easy Installation
*Holes on panels are pre-drilled for fast mounting and securing, perfect for non-permanent installations
*Can be affixed by adhesive, grommets or Velcro (with which you can easily attach or detach the panels)
*Can be installed without costly structural roof reinforcements
3.Widely Compatibility
Boats/Sailboats, Yachts, Marine applications,Motorhomes/RVs, Expedition Vehicles, Commercial Trucks/Trailers, Caravans/Popup Off-Grid and Remote Communication sites and more
5.Reliable
6.Productivity
| Model No. | eRigid M80w SP |
| Product Name | 80W solar panel back contact cell black or silver frame for off grid application with good performance under low light |
| Maximum Power[Wp] | 80 |
| Solar Cell | SunPower Maxeon Gen III Back Contact Cell |
| Cell Array[Pcs] | 4*12 |
| Cell Efficiency | 22.60% |
| Size[mm] | 540*830*30 |
| Max Power Voltage Vmp[V] | 27.84 |
| Max Power Current Imp[A] | 2.87 |
| Open Circuit Voltage Voc[V] | 32.85 |
| Short Circuit Current Isc[A] | 3.03 |
| Power tolerance[%] | ±3% |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/K] | -0.3 |
| Temperature Coefficient Voc[[%/K] | -1.74mV |
| Temperature Coefficient Isc[[%/K] | 0.05 |
| Maximum System Voltage[V] | 1000 V |
| Maximum Reverse Current[V] | 20A |
| Certification | CE ROHS |
| Surface/Backsheet | Glass/silver frame/white PETbacksheet |
| Cables and Connectors | Jbox IP65,2bypass diode,0.9m*4mm2 cable and 1 pair of MC4 connector |
| Standard Test Conditions | STC: 1000W/m², AM 1.5 and cell temp 25°C |
| Package | 1pcs/carton box and plywood pallet |
Our service
Before sale:
1.Our sales representative and engineer work together to answer your questions and offer solution for free;
2.Sales person choose the best solar product for you to make sure it worth its real value;
3.We design the best solution with good perfomance for you,manwhile save every cent of your money.
4.Strict quality control,strict test for all12v 110W solar panel back contact cell black or silver frame for off grid application with good performance under low light,insure the best quality produced.
5.Fast delivery and communication with customer,to let customer know goods status at the earliest.
After sale:
We provide 5 years Warranty for the product, 10 years warranty for 90% power production ,25 years warranty for 80% power production.
Gather feedback from customers,listen to customers and make new and better products.
